BSZ Parts

Wheelie Bar for KTM EXC 2012-2023

€179,90 EUR

Sale Sold out

Shipping calculated at checkout.

In stock

Year of manufacture. All KTM EXC, EXCF, SX and SXF models from the same manufacturing period have an identical subframe. Whether 250, 350 or 500 — it is only important to select the correct year of manufacture variant. 2012-2016 2017-2019 2020-2023

👀 0 people are viewing this product right now

Quantity

📦 Shipping Information

Each Wheelie Bar is individually prepared and carefully assembled after your order. Production time: approx. 1 week. This ensures proper fitment, quality control, and a clean finish before shipping.

The Stuntframe for KTM Supermoto was developed for riders who push their bikes to the limit with wheelies and stunts. Thanks to the folding mechanism, the frame folds away in the event of backward falls instead of bending – this reduces the risk of damage to the subframe.

Made from high-strength structural steel and powder-coated in matte black or white. The grip tape is pre-applied, and the Stuntframe is ready for immediate installation. Developed with real feedback from the Supermoto scene and handcrafted in Austria.

Technical Details:

Folding mechanism to protect the subframe (except 2024–2026)
High-strength, welded structural steel
Powder-coated surface
Pre-applied grip tape
Weight: approx. 1.5 kg
Installation time: approx. 30–60 minutes
A drill may be required depending on the model

Scope of delivery depending on variant:

2012–2016:

Stuntframe
2× M6 screws and nuts (pre-assembled)
Grip tape

2017–2019:

Stuntframe
4× M6 screws
4× M6 self-locking nuts
2× M6 screws and nuts (pre-assembled)
Grip tape

2020–2023:

Stuntframe
4× M6 screws
4× M6 self-locking nuts
2× M6 screws and nuts (pre-assembled)
Grip tape

Installation instructions:

KTM EXC 2012-2016:
For this, you simply need to cut two holes into the rear plastic and remove the black stoppers from the subframe using the M5 screws. Slide the stunt frame into the subframe and secure it from below with the original M5 screws.

KTM EXC 2017-2019:
For this, you simply need to cut two holes into the rear plastic. Slide the stunt frame into the original subframe and then you need to drill through the subframe and simultaneously through the stunt frame with a 6mm drill. Note! Make sure you drill centrally through both the subframe and the stunt frame. Now attach the stunt frame with the 4 included screws.

KTM EXC 2020-2022:
For this, you simply need to cut two holes into the rear plastic. Slide the stunt frame inside next to the original subframe and drill four holes, two on each side, with a 6mm drill. Note! Drill centrally through the stunt frame and at the locations where the holes are already present on the stunt frame. This way, you can secure the stunt frame with the 4 included screws.

KTM EXC 2023-2025:
For this, simply insert the stunt frame into the rear and secure it with the new longer screws. You may need to remove some plastic to make it fit.

Note:

The stunt frame is intended exclusively for use during controlled stunt sessions or on closed courses. Not approved for public road use. Installation or use may void the vehicle's operating license. Use is at your own risk.
